Adopt distinctive dust removal technology, environmental protection Fire box using 50-Cr alloy pipes, fire-resistant temperature of 1700 degrees Celsius and corrosion-resistance, more than 10 years service life. .
Details
Heater specification:
1, 200 thousands large calorie thermal capacity.
2, heating s.m: 300/600/1200s.m
3, Adopt stainless steel heat exchanger (chrome).
4. Stainless steel exchanger is made of 321stainless steel plate, tube.
5, Accuracy numerical controlling system, extend lifetime.
5, Special whole heat-prevention, heat insulation design, heat loss reduces to the lowest.
6, double inlet and double outlet design.
Detailed parameter:
Basic parameters | Unit | BC-5A | BC-10A | BC-20A |
Rated heat | 10 000 kcal | 5 | 10 | 20 |
Thermal efficiency | % | ≥90 | ≥90 | ≥90 |
Hot air outlet temperature | °C | 40-80 | 40-80 | 40-80 |
Rated amount of hot air | m3/h | 9800 | 18000 | 24000 |
Rated fuel consumption | kg/h | 3-6 | 6-12 | 12-24 |
For fuel | Diesel fuel | Diesel fuel | Diesel fuel | Diesel fuel |
Power | kw | 0.87 | 1.27 | 1.82 |
Dimensions | mm | 2050×920×1450 | 2120×1020×1560 | 2220×1120×1560 |
Weight | kg | 250 | 300 | 340 |
Heating area | m2 | 200-400 | 500-700 | 800-1200 |
Blower | kw | 0.75 | 0.55×2 | 0.75×2 |
Material of frame | / | Galvanized +spray paint | Galvanized +spray paint | Galvanized +spray paint |
Quality guarantee period | / | one year warranty lifelong service | one year warranty lifelong service | one year warranty lifelong service |
